| Business Type | Manufacturer, Exporter, Supplier |
| Frequency Range | 1.5 - 30 MHz |
| Polarization | Horizontal Or Inverted 'V' |
| Bandwidth | Full 1.5 To 30 MHz |
| Click to view more | |
Product Details
ELECTRICAL SPECIFICATIONS : Frequency Range 1.5 - 30 MHz. Gain Unity Bandwidth Full 1.5 to 30 MHz. Polarization Horizontal or Inverted "V" Input Impedance 50 Ohms. Radiation Pattern Omni-directional VSWR 2 : 1 RF Power Handling Capacity 500 Watts. Input Termination N-Female Lightning Protection Direct Ground MECHANICAL SPECIFICATIONS: Net Weight 4 Kgs. (antenna only) Wind Rating 160 Km/Hr. Balun Base Diameter 65 mm (Balun) Base Material Nylon (Balun) Overall Length 23 Meters. Shipping Box Size 0.60 x 0.15 x 0.15 Meter Dipole Materials Twisted Copper with Insulator Spreaders Materials PVC Pipe Insulator Materials Nylon Recommended Mast Height 9 Meters (30 Feet) Distance between Mast 25 Meters ENVIRONMENTAL SPECIFICATIONS: Operating Temperature (-)25 to +65 Degrees Celsius Storage Temperature (-)40 to +75 Degrees Celsius Humidity 0 to 95% RH.
