Antenna Mast
Leading Manufacturers, Exporters and Wholesaler of 36 Feet Aluminum Tubular Antenna Mast and 42 Feet Aluminum Tubular Antenna Mast from Delhi.
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Aluminum |
| Country of Origin | Made In India |
| Height | 36 Feet (11 Mtr) |
| Pipe OD | 60 Mm |
| Weight | 20 Kg |
| Wind Speed | 40 Mtr / Sec |
| Set Contains | Rope, Hammer, Mount, Bracket, Bolt, Base Etc |
36 feet Aluminiam tubular mast consists of 6 section, each made of 2" Aluminiam pipes of 6 feet long of minimum 2 mm wall thickness
The section at one end should be dying pressed minimum 6 inches, so that it couples to the other corresponding section properly, Coupling pipe of 12" 2.5mm wall thik For AE mast sections . = (Qty 5)
One base plate galvanized of size, 1.57 x 1.5ft x 5mm with holding pipe and 4 ground pegs of 10 inches and 16mm duly galvanized to be provided for fixing it to the ground Three pes of anchors 38x38x5mm thick of 24 inch long with hole for guy rope fitting to be provided Two sets of pvc ropes (3 guys peg set) to be provided at 30ft and 50ft & one 60 ft pvc rope (Total 300 ft) with suitable rope tightens and thimbles. two heavy duty canvases carry bag to be provided for carrying accessories. 1.5kg Hammer 1 pc., Middle guy plate 1pes, Top guy plate 1 pes, patti =6 ,nut Bolt with washer 3", for coupling of mast Sections. (Qty 21)
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India,Made In India |
| Height | 42 Feet (15 Mtr) |
| Material | Aluminum |
| Pipe OD | 60 Mm |
| Weight | 20 Kg |
| Wind Speed | 40 Mtr/sec |
| Set Contains | Rope, Hammer, Mount, Bracket, Bolt, Base Etc |
42 feet Aluminiam tubular mast consists of 7 section, each made of 2" Aluminiam pipes of 6 feet long of minimum 2 mm wall thickness
The section at one end should be dying pressed minimum 6 inches, so that it couples to the other corresponding section properly, Coupling pipe of 12" 2.5mm wall thik For AE mast sections . = (Qty 5)
One base plate galvanized of size, 1.57 x 1.5ft x 5mm with holding pipe and 4 ground pegs of 10 inches and 16mm duly galvanized to be provided for fixing it to the ground Three pes of anchors 38x38x5mm thick of 24 inch long with hole for guy rope fitting to be provided Two sets of pvc ropes (3 guys peg set) to be provided at 30ft and 50ft & one 60 ft pvc rope (Total 300 ft) with suitable rope tightens and thimbles. two heavy duty canvases carry bag to be provided for carrying accessories. 1.5kg Hammer 1 pc., Middle guy plate 1pes, Top guy plate 1 pes, patti =6 ,nut Bolt with washer 3", for coupling of mast Sections. (Qty 21)Antenna/Tower Height 42 feet (15 mtr)
